Specifications
Standards
Milling technology
Milling drum LA15 including wear protection on the sides
BOMAG BMS 15 L exchangeable toolholder
3 Milling-Drum-speeds, 100, 112, 130
Proportional adjustable water injection, 0-12 l/min
Automatic water saving device
Levelling, 2 sides + slope
Wear-free, digital Milling depth display
Proportional Milling depth adjustment
Two proportional speeds for Milling- depth-adjustment
Hydraulically operated side-plates with 500 mm (right) and 400 mm (left) stroke
Hydraulically operated front mouldboard
Hydraulically rear mouldboard with adjustable preload-pressure
Right side-plate for fast Drum-exchange
Automatic load-control
Automatic distribution of traction
Hydraulically foldable Conveyor with +65° swivel angle
Camera system: 1x discharge belt, 1x on the back
BOMAG Dual Filtration
BOMAG Easy Cut
BOMAG Easy LevelDrive Systems
4 crawler B1 size steerable, front or/and rear
Crab walk
Variable transport speed
Variable operating speed
Mechanical Drum-driveOperation comfort
Fully vibration-isolated operator-platform
Comfort zones at the standing areas for fatigueless operation
Adjustable dashboards
Standardized self-explanatory, well-arranged dashboards
Large storage at ground level
Service- and maintenance-points ergonomic concentrated
Large Storage compartment at the operator platform including 24V plug and flexible layer
Diesel and AdBlue fill comfortable and safely place at the operator station
BOMAG Fast Select for a fast machine operationSafety & environmental protection
Noise optimized design
Liquid cooled engine following latest emission rules without hot exhaust jet to the back
Integrated working lights
Rotary-beacon
Mirrors
CE-conform safety-package with emergency- stop-switches
Back-up-alarm
Options
Basic machine
Track chains B3 size
Storage compartment for cutting tools on the track chains
Weather protection roof
Plexiglas weather protection for the side railings
Water filling pump
High pressure cleaner
Hose reel
Dust reduction system
ION DUST SHIELD
Auxiliary Drum Drive for easy tool exchange
Compressed air system
Additional motor for auxiliary function & emergency drive function
Additional compartment for cutting tool
Additional working-light, magnet base
Advanced lighting package – additional 142.000 lm
Ballast weights
Special colour
Biodegradable hydraulic oil
Slewable standing support
Vandalism protectionMilling technology
Quick-exchange drum-system
Milling-Drum 2000, BMS 15 L, LA15
Milling-Drum 2200, BMS 15 L, LA15
Milling-Drum 2000, BMS 15 L, LA8
Milling-Drum 2200, BMS 15 L, LA8
POWER DRUM 2000, BMS 15 L, LA23
POWER DRUM 2200, BMS 15 L, LA23
Additional Milling Drum BearingLevelling Systems and electronic support
Additional external BOMAG Easy Level Display
2 scanners left & right in front of the milling box
Camera system: 2 additional camera’s, 1x downholder, 1x rear scraper
BOMAG TELEMATIC
