Go from Paper to Precision with Smart Construction Design
- Shelley Devine
- Jul 10
- 2 min read
Updated: Aug 6
Make the leap from 2D plans to 3D-ready job sites.
Still working from paper plans? It’s time to upgrade. With Smart Construction Design, you can convert traditional 2D drawings into detailed 3D models that are optimized for both machines and project planning. Whether you’re just breaking ground or prepping for final grading, accurate 3D design files ensure your job gets done faster, smoother, and with fewer surprises.
Why Make the Move to 3D?
Time is money — and manually recreating paper plans can burn through both. With Komatsu’s 3D data generation service, you can save valuable hours by outsourcing the conversion process. The result? Precise, shareable 3D models ready for use in your machines and management platforms.
🔹 Save time converting plans into digital formats
🔹 Receive accurate 3D models optimized for use in intelligent Machine Control (iMC)
🔹 Easily update and share designs across the team
🔹 Free up internal staff to focus on core operations
🔹 Lay the groundwork for true digital transformation
Already using Smart Construction Office and Field? Design files integrate seamlessly, helping you track progress and production with data you can trust.
Key Features That Bring Plans to Life
✅ Accurate 3D Models
Visualize your site in multidimensional form and share it across your project team. These models update easily as the work progresses — keeping everyone aligned.
✅ Optimized for Machine Control
Design files are tailored for Komatsu’s iMC-equipped machines and compatible with many aftermarket grade control systems, ensuring efficient performance in the field.
✅ Free Up Staff
Let your team focus on running the job site. Smart Construction Design gives you pro-level modeling without tying up your in-house resources.
✅ Digitize Your Job Sites
The sooner you ditch the rolled-up blueprints, the sooner you can start digging with confidence. With precise data behind every move, you'll improve accuracy, reduce rework, and move more material efficiently.
Partner with C.N. Wood to Launch Your Digital Designs
We’ll help you convert your plans and integrate your 3D data with 3D Machine Guidance, Smart Construction Office, and Remote for full visibility from day one.
👉 Contact our team to get started with 3D data generation today.
👉 Need help preparing for your first iMC project? We’ve got your back.
